New Xaar 501 GS8 Printhead

Xaar 501 GS8 Printhead

Xaar 501 GS8 OR Printhead - XP50100038
Xaar 501 GS8 O Printhead - XP50100009
Xaar 501 GS8 U Printhead - XP50100001
Xaar 501 GS8 UR Printhead - XP50100034

The new Xaar 501 printhead reaches higher levels of performance in inkjet graphics. Whether printing large exterior banners or indoor point-of-sale material, this premium printhead delivers exceptional print quality, excellent reliability and high production up-time. Value added effects such as printing on transparent or coloured substrates or adding varnishes are made easy with the Xaar 501.

The new and unique PrecisionPlus architecture of the Xaar 501 builds on Xaar’s incredibly successful Hybrid Side Shooter architecture. This new architecture optimises the actuator performance giving more uniform drop formation across the print swathe and therefore exceptional print quality for stunning graphics.

PrecisionPlus architecture flips the PZT’s (Piezo actuators) supporting substrate on its side so the PZT is on the edge of a rigid block of substrate. This architecture means that there is more stiffness in the z axis (better support for the PZT).

This Xaar 501 GS8 OR is suitable for oil-based printers with a recirculation ink system.

The ability to print high viscosity or heavily pigmented inks such as white becomes a practical reality with TF Technology in Pulsed mode or High Flow mode. Any debris or air bubbles in the printhead are continuously cleared from the rear of the nozzles and removed.

Specifications
Active nozzles : 500
Print swathe width : 70,5mm
Number of rows : 1
Nozzle density : 180 Npi
Nozzle Guard : WFG
Ink types : Oil
Drop volume : 8 – 40pl
Number of grey level* : 6
Filter : No
Heater : No
TF Technology mode : None, Pulsed, High flow mode
Typical firing frequency @ Max DPD*: 8khz
Dimensions (WxDxH) : 104 x 17 x 100mm
Jetting orientation : Downshooter and Skycraper (see picture)
Inlet / Outlet connections : Hose barb 4mm

We offer a manufacturer 12 months  warranty on all Xaar printheads.


Grapo
    Octopus
    Octopus X4

HP
    Scitex FB6300

JHF Vista
    3506B
    3508B
    5006B

Oasis
    3504-CC

Teckwin
    Teckthunder 2400UV
    Tecksmart UV1600
    TeckStorm R
    TeckStorm XL

Zünd
    UVjet 215-C
    UVjet 215-Plus
